Pienten teollisuusrobottien edelläkävijä
Uudet Racer-robotit tarjoavat parasta tehokkuutta ja huipputeknologiaa pienten teollisuusrobottien luokassa. Racer yhdistää nopeuden, sulavaliikkeisyyden ja tyylikkään italialaisen muotoilun ja asettaa riman uudelle korkeudelle luokassaan.
| Robot Type | SCARA |
| Number of axes | 6 |
| Maximum wrist payload (Kg) | 7 |
| Additional load on forearm (Kg) | 10 |
| Maximum horizontal reach (mm) | 999 |
| Torque on axis 5 (Nm) | 13 Nm |
| Torque on axis 5 (Nm) | 13 Nm |
| Torque on axis 6 (Nm) | 7.5 Nm |
| Stroke on Axis 1 | +/- 165° (250°/s) |
| Stroke on Axis 2 | -65°/ +150° (250°/s) |
| Stroke on Axis 3 | -165° / +37° (300°/s) |
| Stroke on Axis 4 | +/- 210° (550°/s) |
| Stroke on Axis 5 | +/- 137° (550°/s) |
| Stroke on Axis 6 | +/- 2700° (600°/s) |
| Repeatability (mm) | 0.05 mm |
| Tool coupling flange | ISO 9409 – 1 – A 40 |
| Robot weight (Kg) | 173 kg |
| Protection class | IP65 |
| Mounting position | Floor / Ceiling / Sloping / Wall |
| Operating Areas A (mm) | 1279 mm |
| Operating Areas B (mm) | 999 mm |
| Operating Areas C (mm) | 904 mm |
| Operating Areas D (mm) | 554 mm |
| Operating Areas E (mm) | 385 mm |
What Racer 999 can do
Assembly, Cosmetic sealing, Handling / Packaging, Machine tending, Measuring / Testing, Polishing and Deburring, Vision System
Racer 999 works with
Controllers CG5 C5 Compact
Teach Pendant TP5
Racer 999 auxiliary systems
Positioners MP TR PDTV PTDO
External Axes External Axes
Slides TMF
Payload: Small 0-16 KG
Reach: up to 1
Application: Assembly, Cosmetic sealing, Handling / Packaging, Machine tending, Measuring / Testing, Polishing and Deburring, Vision System
Industry: Machine Automation, Metal and Arc Welding, Electronics, Consumer Goods, Automotive, Edu, Business Development
