Kun suorituskyky ratkaisee
Tehoa ja nopeutta tuotantoosi. Robotti, joka tuo energiansäästöä, alentaa kuluja ja parantaa tuottavuutta.
| Number of axes | 6 |
| Maximum wrist payload (Kg) | 220 |
| Additional load on forearm (Kg) | 50 |
| Maximum horizontal reach (mm) | 2701 |
| Torque on axis 5 (Nm) | 1230 Nm |
| Torque on axis 5 (Nm) | 1230 Nm |
| Torque on axis 6 (Nm) | 712 Nm |
| Stroke on Axis 1 | +/- 180° (100°/s) |
| Stroke on Axis 2 | -95°/ +75° (90°/s) |
| Stroke on Axis 3 | -10° / -256° (110°/s) |
| Stroke on Axis 4 | +/- 210° (600°/s) |
| Stroke on Axis 5 | +/- 2700° (130°/s) |
| Stroke on Axis 6 | +/- 125° (130°/s) |
| Repeatability (mm) | 0.08 mm |
| Tool coupling flange | ISO 9409 – 1 – A 160 |
| Robot weight (Kg) | 1220 kg |
| Protection class | IP65 / IP67 |
| Mounting position | Floor / Ceiling |
| Operating Areas A (mm) | 3131 mm |
| Operating Areas B (mm) | 2701 mm |
| Operating Areas C (mm) | 2286 mm |
| Operating Areas D (mm) | 786 mm |
| Operating Areas E (mm) | 425 mm |
What NJ 220 – 2.7 can do
Assembly, Cosmetic sealing, Dispensing, Handling / Packaging, Laser welding cutting, Machine tending, Measuring / Testing, Plasma cutting/ water jet, Polishing and Deburring, Press brake-bending, Process machining, Wood/glass machining, Spot welding, Vision System, Press to press
NJ 220 – 2.7 works with
Controllers CG5
Teach Pendant TP5
NJ 220 – 2.7 auxiliary systems
Positioners MP TR PDTV PTDO
External Axes External Axes
Slides TMF
Payload: High 60-300 KG
Reach: 2-3
Application: Assembly, Cosmetic sealing, Dispensing, Handling / Packaging, Laser welding cutting, Machine tending, Measuring / Testing, Plasma cutting/ water jet, Polishing and Deburring, Press brake-bending, Process machining, Wood/glass machining, Spot welding, Vision System, Press to press
Industry: Machine Automation, Metal and Arc Welding, Electronics, Consumer Goods, Automotive, Edu, Business Development
